Specifications

PRICING

Price	Standard
Price - Warranty (Months)	12
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	V Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	96.5
Engine - Horsepower (kW)	72
Engine - Horsepower RPM	8000
Engine - Torque (Ft Lbs)	69.3
Engine - Torque (Nm)	94
Engine - Torque RPM	6500
Engine - Cooling	Liquid
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	DOHC
Engine - Bore (mm)	100
Engine - Bore (in)	3.94
Engine - Stroke (mm)	60
Engine - Stroke (in)	2.36
Engine - Displacement (cc)	942
Engine - Displacement (ci)	57.5
Engine - Compression Ratio	11.5:1
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	2
Carburetion - Carburetor Size (mm)	43
Carburetion - Carburetion Type	Carburetor

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Wheelbase (in)	59.4
Dimensions - Wheelbase (mm)	1508.8
Dimensions - Ground Clearance (in)	7.5
Dimensions - Ground Clearance (mm)	190.5
Weight	Standard
Weight - Dry Weight (lbs)	421
Weight - Dry Weight (kg)	191
Capacities	Standard
Capacities - Fuel Capacity (gal)	4.6
Capacities - Fuel Capacity (l)	17.4
Performance	Standard
Performance - Engine Displacement to Weight (cc)	2.24

EXTERIOR

Construction	Standard
Construction - Frame	Chromium Molybdenum
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver and Passenger
Exterior Guards	Standard
Exterior Guards - Chain Guard	Yes
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Belt Guard	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Center / Kick
Lower Fairing	Standard
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Inverted Fork
Front Suspension - Front Suspension Size (in)	1.9
Front Suspension - Front Suspension Size (mm)	48
Front Suspension - Front Travel (in)	7.9
Front Suspension - Front Travel (mm)	200
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Front Suspension Brand Name	WP
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	8.3
Rear Suspension - Rear Travel (mm)	210
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Front Wheel Width (in)	3.5
Wheels - Rear Wheel Width (in)	5.5
Tires	Standard
Tires - Front Tire Width	120
Tires - Front Tire Aspect Ratio	70
Tires - Front Wheel Diameter	17
Tires - Rear Tire Width	180
Tires - Rear Tire Aspect Ratio	55
Tires - Rear Wheel Diameter	17
Tires - Front Tire (Full Spec)	120/70 R17
Tires - Rear Tire (Full Spec)	180/55 R17

BRAKES

Brakes	Standard
Brakes - Brake Brand Name	Brembo®
Brakes - Front Brake Type	Dual Disc
Brakes - Front Brake Diameter (in)	12
Brakes - Front Brake Diameter (mm)	305
Brakes - Rear Brake Type	Disc
Brakes - Rear Brake Diameter (in)	9.5
Brakes - Rear Brake Diameter (mm)	240

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver and Passenger
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	34
Seat Specifications - Seat Height (mm)	863.6
Seat Specifications - Number Of Seats	2
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Trip Odometer	Standard
Speedometer	Standard
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Light

STORAGE

Underseat Storage	Standard
Rear Rack	Standard

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Rearview Mirrors

Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No
Decal Kit	Standard

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

MOUNTS

Windshield Mounts

Standard

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
