Specifications

PRICING

Price	Standard
Price - Warranty (Months)	36
Price - Warranty (Condition)	Limited
Price - Basic Warranty (Miles)	36000

ENGINE

Engine	Standard
Engine - Engine Type	Flat Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	105
Engine - Horsepower (kW)	77
Engine - Horsepower RPM	7500
Engine - Torque (Ft Lbs)	85
Engine - Torque (Nm)	115.2
Engine - Torque RPM	5750
Engine - Cooling	Air / Oil
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	OHV
Engine - Bore (mm)	101
Engine - Bore (in)	3.98
Engine - Stroke (mm)	73
Engine - Stroke (in)	2.88
Engine - Displacement (cc)	1170
Engine - Displacement (ci)	71.4
Engine - Compression Ratio	12.0:1
Engine - Starter	Electric
Engine - Fuel Requirements	Premium
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Fuel Injector	Yes
Carburetion - Fuel Injector Size (mm)	47
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Overdrive	Yes
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Gear Ratio (1)	2.38
Transmission - Gear Ratio (2)	1.65
Transmission - Gear Ratio (3)	1.3
Transmission - Gear Ratio (4)	1.07
Transmission - Gear Ratio (5)	0.96
Transmission - Gear Ratio (6)	0.84
Transmission - Reverse	No
Transmission - Final Drive Ratio	2.91

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	87
Dimensions - Length (mm)	2210
Dimensions - Width (in)	36.6
Dimensions - Width (mm)	929.6
Dimensions - Wheelbase (in)	59.3
Dimensions - Wheelbase (mm)	1506.2
Dimensions - Length (ft)	7.25
Dimensions - Length (ft/ft)	7
Dimensions - Length (ft/in)	3
Weight	Standard
Weight - Wet Weight (lbs)	504
Weight - Wet Weight (kg)	228.6
Weight - GVWR (lbs)	968
Weight - GVWR (kgs)	439.1
Capacities	Standard
Capacities - Fuel Capacity (gal)	5.3
Capacities - Fuel Capacity (l)	20
Capacities - Fuel Capacity Reserve (gal)	1
Capacities - Fuel Capacity Reserve (l)	3.8
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Aluminum / Steel
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver and Passenger
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Chassis Protectors	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Tank Guard	Yes
Exterior Guards - Belt Guard	No
Exterior Covers	Standard
Exterior Covers - Radiator Cover	No
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Center / Kick
Handlebars	Standard
Skid Plate	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Travel (in)	7.5
Front Suspension - Front Travel (mm)	190
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	Yes
Front Suspension - Front Suspension Brand Name	Telelever
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Single Sided Swing Arm
Rear Suspension - Rear Travel (in)	7.9
Rear Suspension - Rear Travel (mm)	200
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	Paralever
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubeless
Wheels - Front Wheel Width (in)	2.5
Wheels - Rear Wheel Width (in)	4
Wheels - Chromed	Yes
Tires	Standard
Tires - Front Tire Width	110
Tires - Front Tire Aspect Ratio	80
Tires - Front Tire Speed Rating	H
Tires - Front Wheel Diameter	19
Tires - Rear Tire Width	150
Tires - Rear Tire Aspect Ratio	70
Tires - Rear Tire Speed Rating	H
Tires - Rear Wheel Diameter	17
Tires - Front Tire (Full Spec)	110/80 HR19
Tires - Rear Tire (Full Spec)	150/70 HR17

BRAKES

Brakes	Standard
Brakes - Brake Brand Name	EVO
Brakes - Front Brake Type	Dual Hydraulic Disc
Brakes - Front Brake Diameter (in)	12
Brakes - Front Brake Diameter (mm)	305
Brakes - Rear Brake Type	Hydraulic Disc
Brakes - Rear Brake Diameter (in)	10.4
Brakes - Rear Brake Diameter (mm)	265
Anti-Lock Brakes	Standard
Linked Brake System Front to Rear	Standard

SEATS

Seat	Standard
Seat - Seat Type	Two-Piece
Seat - Adjustable	Yes
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver and Passenger
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	33.5
Seat Specifications - Seat Height (mm)	850
Seat Specifications - Number Of Seats	2
Detachable Passenger Seat	Standard
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Tachometer	Standard
Trip Odometer	Standard
Trip Computer	Standard
Speedometer	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Gauge
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge
Service Reminder	Standard

STORAGE

Rear Rack

Standard

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Rearview Mirrors	Standard
Windshield	Standard
Windshield - Windshield Lowers	No
Windshield - Height Adjustable	Yes
Windshield - Tinted	Yes
Windshield - Height	Low

CONVENIENCE

Engine Immobilizer	Standard
Power Outlet	Standard
Adjustable Handlebars	Standard
Adjustable Levers	Standard

PAINT & FINISH

Paint	Standard
Decal Kit	Standard

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

MOUNTS

Windshield Mounts

Standard

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
