Specifications

PRICING

Price	Standard
Price - Warranty (Months)	1
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Liquid
Engine - Valves	4
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	DOHC
Engine - Bore (mm)	97
Engine - Bore (in)	3.82
Engine - Stroke (mm)	60.8
Engine - Stroke (in)	2.39
Engine - Displacement (cc)	449
Engine - Displacement (ci)	27.4
Engine - Compression Ratio	12.8:1
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Keihin
Carburetion - Fuel Injector	Yes
Carburetion - Fuel Injector Size (mm)	44
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	5
Transmission - Overdrive	Yes
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	86
Dimensions - Length (mm)	2184.4
Dimensions - Width (in)	32.5
Dimensions - Width (mm)	825.5
Dimensions - Height (in)	50.6
Dimensions - Height (mm)	1285.2
Dimensions - Wheelbase (in)	58.5
Dimensions - Wheelbase (mm)	1485.9
Dimensions - Ground Clearance (in)	13
Dimensions - Ground Clearance (mm)	330.2
Dimensions - Length (ft)	7.17
Dimensions - Length (ft/ft)	7
Dimensions - Length (ft/in)	2
Weight	Standard
Weight - Wet Weight (lbs)	245
Weight - Wet Weight (kg)	111.1
Capacities	Standard
Capacities - Fuel Capacity (gal)	1.6
Capacities - Fuel Capacity (l)	6.1
Performance	Standard
Performance - Engine Displacement to Weight (cc)	1.71

EXTERIOR

Construction	Standard
Construction - Frame	Aluminum
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Chain Guard	Yes
Exterior Guards - Chassis Protectors	Yes
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Tank Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	No
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Exterior Covers - Fuel Tank Cover	No
Front Fender	Standard
Rear Fender	Standard
Handlebars	Standard
Handlebar Pads	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Inverted Fork
Front Suspension - Front Travel (in)	12.2
Front Suspension - Front Travel (mm)	309.9
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Front Suspension Brand Name	KYB
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	12.5
Rear Suspension - Rear Travel (mm)	317.5
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	KYB
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubed
Wheels - Chromed	Yes
Tires	Standard
Tires - Tire Brand	Dunlop®
Tires - Front Tire Width	80
Tires - Front Tire Aspect Ratio	100
Tires - Front Wheel Diameter	21
Tires - Rear Tire Width	120
Tires - Rear Tire Aspect Ratio	80
Tires - Rear Wheel Diameter	19
Tires - Front Tire (Full Spec)	Dunlop® MX3S 80/100 R21
Tires - Rear Tire (Full Spec)	Dunlop® MX3S 120/80 R19

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Front Brake Diameter (in)	10.6
Brakes - Front Brake Diameter (mm)	270
Brakes - Rear Brake Type	Hydraulic Disc
Brakes - Rear Brake Diameter (in)	9.7
Brakes - Rear Brake Diameter (mm)	245

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	38.6
Seat Specifications - Seat Height (mm)	980.4
Seat Specifications - Number Of Seats	1

CONVENIENCE

Adjustable Handlebars	Standard
Adjustable Levers	Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
