Specifications

PRICING

Price	Standard
Price - Warranty (Months)	36
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	Parallel Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	47
Engine - Horsepower (kW)	35.1
Engine - Horsepower RPM	7250
Engine - Torque (Ft Lbs)	38.4
Engine - Torque (Nm)	52
Engine - Torque RPM	5250
Engine - Cooling	Air / Oil
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	SOHC
Engine - Displacement (cc)	648
Engine - Displacement (ci)	39.5
Engine - Compression Ratio	9.5:1
Engine - Starter	Electric / Kick
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Bosch
Carburetion - Fuel Injector	Yes
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected
Parental Controls - Speed Governor	No

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Overdrive	No
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	83.5
Dimensions - Length (mm)	2122
Dimensions - Width (in)	40.3
Dimensions - Width (mm)	1024
Dimensions - Height (in)	29.3
Dimensions - Height (mm)	744
Dimensions - Wheelbase (in)	55
Dimensions - Wheelbase (mm)	1398
Dimensions - Ground Clearance (in)	6.9
Dimensions - Ground Clearance (mm)	174
Dimensions - Length (ft)	6.96
Dimensions - Length (ft/ft)	6
Dimensions - Length (ft/in)	11.5
Weight	Standard
Weight - Dry Weight (lbs)	435
Weight - Dry Weight (kg)	198
Capacities	Standard
Capacities - Fuel Capacity (gal)	3.3
Capacities - Fuel Capacity (l)	12.5
Performance	Standard
Performance - Engine Displacement to Weight (cc)	1.48

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Chain Guard	Yes
Exterior Guards - Chassis Protectors	No
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Center / Kick
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Suspension Size (in)	1.6
Front Suspension - Front Suspension Size (mm)	41
Front Suspension - Front Travel (in)	4.3
Front Suspension - Front Travel (mm)	110
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	3.5
Rear Suspension - Rear Travel (mm)	88
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	No
Rear Suspension - Number Rear Shock Absorbers	2
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubed
Wheels - Front Wheel Width (in)	2.5
Wheels - Rear Wheel Width (in)	3.5
Wheels - Chromed	No
Tires	Standard
Tires - Tire Brand	Pirelli®
Tires - Front Tire Width	100
Tires - Front Tire Aspect Ratio	90
Tires - Front Wheel Diameter	18
Tires - Rear Tire Width	130
Tires - Rear Tire Aspect Ratio	70
Tires - Rear Wheel Diameter	18
Tires - Front Tire (Full Spec)	Pirelli Phantom Sportcomp 100 / 90 R18
Tires - Rear Tire (Full Spec)	Pirelli Phantom Sportcomp 130 / 70 R18

BRAKES

Brakes	Standard
Brakes - Brake Brand Name	Brembo®
Brakes - Front Brake Type	Disc
Brakes - Front Brake Diameter (in)	12.6
Brakes - Front Brake Diameter (mm)	320
Brakes - Rear Brake Type	Disc
Brakes - Rear Brake Diameter (in)	9.4
Brakes - Rear Brake Diameter (mm)	240
Anti-Lock Brakes	Standard

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	31.2
Seat Specifications - Seat Height (mm)	793
Seat Specifications - Number Of Seats	1

INSTRUMENTATION

Tachometer	Standard
Speedometer	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Light
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Light

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Rearview Mirrors

Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
